Impact Crusher
Impact Crusher

PF Impact Crusher is used for primary, secondary and fine crushing of all kinds of stones and rocks with anti-pressure strength less than 350 MPa such as granite, marble, and limestone. PF Impact Crusher is widely used for sand and rock production in the industry of roads, railways, reservoir, electricity power, building materials, etc.

Working Principle

The materials are crushed via impact energy produced in the impact crusher. When the materials enter the zone of the board hammer, they are flung into the impact equipment via the high-speed impact of the board hammer. These materials will be re-crushed after rebounding into the scale board. The large materials are crushed into small pieces until it becomes the specified granularities. The end products come out from the base of the impact crusher.

Performance Feature

1. Cubic-shaped end products

2. Adjustable end products sizes, simple crushing process

3. The board hammer is made of high chrome and, abrasion-resistant and with powerful impacting force

4. Non-key connected, easy to maintain, cost-saving

5. Sound construction and high efficiency

6. High crushing ratio, comprehensive functions and good wearing resistance
